Elbow Engine Plans

Complete plans to build a unique 5-cyliner steam engine.

These plans were created by Bill Reichart.

This steam engine has 10 pistons and no crankshaft. The plans include six pages of detailed drawings and construction notes. The engine is made from bar stock. No castings are required.
