3-Axis DRO Kit, Tilting Column Mini Mill, Bluetooth

3-Axis DRO Kit, Tilting Column Mini Mill, Bluetooth

5492

$499.95 USD
$499.95 USD
Sale Sold out
Shipping calculated at checkout.

In stock

Key Features

  • Fits most tilting column mini mills
  • Displays on any Android tablet with Bluetooth capability
  • Resolution of 0.0002" (0.005 mm)
  • 120 -240 VAC Power supply
  • Coolant and dust resistant (IP50)

WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

View full details

Product Information

Description

This magnetic technology mini mill DRO package fits most tilting column mini mills.

This package includes what you need to put a DRO on most mini mills. This 3-axis digital readout for milling machines includes a three scales, three read heads, a Bluetooth transceiver and all the mounting brackets and hardware.

You must also get an Android tablet for the display on this DRO. We recommend a 7" screen size, and the tablet must have Bluetooth capability.

***NOTE: This is not a simple "plug in" accessory that requires installation. Please review the instructions in Chris's Tips before purchase.

Chris's Tips

While we sell an Android Tablet with the DRO software installed, you can use most any Android tablet that supports Bluetooth with the Bluetooth DROs that we sell.

Here's how to get going:

  1. On your Android tablet, go to Bluetooth Settings and Pair the DRO to your tablet. The name of the DRO is HC-06 or BT04-E. The PIN is 1234.
  2. Go to the Google Play Store and install Yuriy's Toys TouchDRO.
  3. When you launch TouchDRO and tap Connect in the upper right corner.

Specifications

Repeatability: 0.000" (0.005 mm)

Resolution: 0.000" (.005 mm)

Specified Accuracy: 0.002" / 1 m travel, 0.05 mm

Accuracy / Foot: 0.002" (.05 mm)

Accuracy / 100 Mm: 0.002" (.05 mm)

Scales Cut to Length by User: YES

Scale Technology: Magnetic

Scale Protection: Coolant & dust resistant

Voltage: 120-240 V

Voltage: 100-240 V

Clear to Zero: YES

Direct Entry of Position: YES

Inch/mm Display: YES

Power Off Memory: NO

Reversible Count Direction: YES

Find Center: YES

Bolt Circles: YES

Bolt Lines: YES

Preset Points: YES

Tool Offsets: YES

Radius/Diameter: YES

Incremental/Absolute: YES

Calculator: NO

Arc Machining: NO

Linear Error Compensation: NO

Made In: China

Warranty: 1 years

Warranty: 1 year

Phone Tech Support: Free

Product Compatibility

This product was designed for machines manufactured by SIEG, including those listed below. We have added compatibility for other non-SIEG machines when a “fit” can be verified.

If your machine is not listed, we cannot verify compatibility but encourage you to contact us. With additional information we may be able to help you find a solution.

  • Bolton XJ-9510 Mill/Drill
  • Clarke CMD300 Milling Drilling Machine
  • Grizzly G8689 Mini Milling Machine
  • Hare & Forbes HM-10 Mill/Drill
  • Princess Auto 8507667 Powerfist Mini Mill
  • SIEG X2-MT3 Mini Mill
  • Micro-Mark 82573 MicroLux Milling Machine
  • BusyBee CX605 Craftex Mini Mill
  • Cummins (Tools Now) 7877 Mini Mill
  • Eastwood 32498 Mini Mill
  • Harbor Freight 44991 Central Machinery Mill/Drill
  • Homier 03947 Speedway Mini Mill
  • King Canada KC-15VS King Industrial Mini Mill
  • Northern Tool 49657 KLUTCH Mini Mill
  • Penn Tool Co XJ-9510-1 Precise Mini Mill
  • SIEG X2-R8 Mini Mill
  • Travers Tools OT2213 OTMT Mini Mill
  • BusyBee CX612 Craftex Mini Mill
  • SIEG SX2 Mini Mill
  • Micro-Mark 84630 MicroLux Mini Mill

Product Instructions
