LittleMachineShop.com measurement tools are all best-in-class products. Whether you want an economical starter kit or a top-of-the-line tool, we have you covered. Also, check out our full line of tooling, accessories and replacement parts. As always, we stand behind our products 100% and provide US based tech support for everything we sell.

3708 Bore Gage Set, 2-6" Dial, Dasqua

Measure ID of holes from 2" to 6" in diameter
Close tolerance measurement of ID, taper and roundness
Furnished with AGD Group II dial indicator
Accuracy: 0.0005"
Includes fitted case and interchangeable anvils

This dial bore gage is easy to calibrate with a ring gage or micrometer.

1593 Dial Indicator and Magnetic Base, Dasqua

0-1" Dial indicator
Magnetic base with fine adjustment
Permanent magnet has an 80 kg (176 lb) holding force
On/off switch makes it easy to position
V-groove base allows you to mount it on cylindrical surfaces

This 1" stroke magnetic dial indicator features large, easy to read numbers and crisp graduations. Each revolution is 0.100", indicated by the revolution counter. The resolution is 0.001". There is a mounting lug on the back of the case. The 1593 Dial Indicator and Magnetic Base has a fine adjustment feature. The on/off switch makes it easy to position. The v-groove base allows you to mount it on cylindrical surfaces. The permanent magnet has an 80 kg (176 lb) holding force.

6230 Dial Indicator, 0-1", Magnetic Back, Dasqua

0-1" dial indicator with 0.001" resolution
0.375" Shank, #4-48 Tip Thread of Hardened Stainless
AGD Group 2, 2" Diameter Face
Magnetic Back is 2 1/4" in Diameter and Coated, Screws On/Off
High Quality Dasqua Brand

This 1" stroke dial indicator features large, easy to read numbers and crisp graduations. Each revolution is 0.100", indicated by the revolution counter. The resolution is 0.001". There is a screw on/off magnetic back which has a protective coating. The Indicator shank is 3/8" (0.375") in diameter, made of hardened stainless steel and has a #4-48 tip thread.

4285 Dial Indicator, 0.5" x 0.001", Professional Grade, Dasqua

Dasqua brand guarantees professional quality
0-0.5" dial indicator with 0.001" resolution
6 jewel shock resistant movement
1.5" dial diameter AGD Group 1 with 0.375" shank and flat back
Calibration certificate included

This 0.5" stroke dial indicator features large, easy to read numbers and crisp graduations. Each revolution is 0.050", indicated by the revolution counter. The resolution is 0.001". The thread for the tip is #4-48. Includes a durable plastic case. This indicator is made and inspected in the same factory as some of Europe's best-known brands.

6556 Dial Indicator, 2" x 0.001", Dasqua

0-2" dial indicator with 0.001" resolution
AGD Group 2
2.25" Diameter face, 0.375" shank, #4-48 tip thread

This 2" stroke dial indicator features large, easy to read numbers and crisp graduations. Each revolution is 0.100", indicated by the revolution counter. The resolution is 0.001". There is a mounting lug on the back of the case. This indicator is about 10" long overall.

5377 Electronic Digital Indicator, 0.5", Dasqua

0.5" digital electronic AGD Group 2 indicator
Range .500" (12.7mm)
Resolution .0005" (.01mm)
Reverse travel (± control indicates direction)
True inch/mm conversion

This electronic digital indicator features a large, easy to read LCD display. You can set zero at any position and change the direction that shows positive dimensions. The indicator has a 3/8" shank and the tip thread is #4-48. The case has a mounting lug on the back. Front battery cover allows easy access to change battery. Extra large LCD display. Absolute zero reset button. Zero at any point. On/Off button. Flat Back with Lug Back included Battery included: SR44, 1.55V. Supplied with fitted case.

2062 Magnetic Base Indicator Holder, Dasqua

Magnetic base indicator holder
110 lbs pull with 220mm (8.66") arm length
Tight locking force
Dovetail groove for test indicators
Three clamping holes, 6mm, 8mm and 3/8"

Magnetic base indicator holder with a strong 110 lb. pull. The indicator arm is 220mm (8.66"). Unit has three clamping holes (6mm, 8mm and 3/8") for use with metric and inch dial indicators. There is a dovetail groove for test indicators. The tightening knob is designed for comfortable grip. Constructed from high grade hardened steel and made on CNC machines for an accurate fit.

1237 Magnetic Base Indicator Holder, Dasqua

Magnetic base indicator holder with fine adjustment
Permanent magnet has an 60 kg (130 lb) holding force
On/off switch makes it easy to position
V-groove base allows you to mount it on cylindrical surfaces
Works with most AGD dial and test indicators

This magnetic base indicator holder has a fine adjustment feature. The on/off switch makes it easy to position. The V-groove base allows you to mount it on cylindrical surfaces. The permanent magnet has an 60 kg (130 lb) holding force.

2064 Master Precision Level, 6", Dasqua

6" Master Precision Level
Cast iron with precision ground measuring surface
Bubble has 0.005" graduation
Overall accuracy is 0.0005" per 10"
V-grooved base for round stock

Ensure a level setup with this 6" master precision level. Made in strict accordance with DIN877 standard, this level is used to measure the straightness and flatness of machine guide rails. Made of cast iron with a precision ground measuring surface. A V-grooved base allows for use on round stock, shafts and cylindrical surfaces. Includes a main vial and a cross test vial. High-sensitivity bubble with 0.005" graduations and an accuracy of 0.0005" per 10".

2065 Master Precision Level, 8", Dasqua

8" Master Precision Level
Cast iron with precision ground measuring surface
Bubble has 0.005" graduation
Overall accuracy is 0.0005" per 10"
V-grooved base for round stock

Ensure a level setup with this 8" master precision level. Made in strict accordance with DIN877 standard, this level is used to measure the straightness and flatness of machine guide rails. Made of cast iron with a precision ground measuring surface. A V-grooved base allows for use on round stock, shafts and cylindrical surfaces. Includes a main vial and a cross test vial. High-sensitivity bubble with 0.005" graduations and an accuracy of 0.0005" per 10".

5967 Telescoping Gage Set, 6-Piece 5/16 - 6", Dasqua

For measuring holes, slots and recesses
Measures holes from 5/16" to 6" diameter
Double action is self-centering
Satin chrome finish
Contact ends are hardened and ground

Use telescoping gages to measure ID, deep holes, recesses, slots, grooves, and other hard to reach places. Measure the actual size or lock the self-centering plungers to a known size for a go-no go gage.

6269 Thread Checker, Dasqua

More robust than plastic checkers
Each size has a nut and bolt checker on the same gauge with the sizes etched on each gage
The individual gauges rotate freely on the wire cable for fast thread verification
All on a convenient wire cable with a loop for hanging

This thread checker set provides a quick and easy way to measure standard threads in both inches and metric. They provide all the information you need for screws; diameter, length, threads per inch, hole size and even tap drill sizes. Each piece has a mail and female end to help you identify screws, nuts, or other threaded items. The metal construction removes the issue of damaging the checker when testing threading which is sometimes an issue with plastic checkers. Inch Sizes Included: #6-32, #8-32, #10-24, #10-32, 1/4-20, 1/4-28, 5/16-18, 5/16-24, 3/8-16, 3/8-24, 7/16-14, 7/16-20, 1/2-13, 1/2-20 Metric Sizes Included: M4 x 0.7, M5 x 0.8, M6 x 1.0, M7 x 1.0, M8 x 1.0, M8 x 1.25, M10 x 1.0, M10 x 1.25, M10 x 1.5, M12 x 1.25, M12 x 1.5, M12 x 1.75 Note: Spacer beads may vary in color and style.
