We carry a full line of digital position readouts for lathes and mills.

6387 2-Axis DRO Kit, Bench Lathe with Rotating Arm

Hard wired 2-axis DRO package with mounting arm
Designed for LittleMachineShop.com HiTorque bench lathes
Complete package, no additional components needed
Advanced display functions
Rotating arm included

Hard wired DRO kit for the HiTorque bench lathe. This kit comes with everything you need for a lathe 2-axis DRO installation. The wiring setup eliminates the need for a wireless environment and ensures regular steady connectivity to your lathe. The display has a protective cover which can be used or removed based on your preferences. The read head cable is approximately 58" between read head and an 9-Pin connector. The scales are pre-cut to length for the HiTorque bench lathe. See the Compatibility tab for products that work with this product.

5516 3-Axis Digital Readout Display

3-axis digital display works with magnetic DRO scales
X, Y, and Z buttons reset the individual axis displays to 0.000
Display can be changed from inches to mm
Resolution: 0.001"

The 3-Axis digital display mounts magnetically. The display is 100 mm x 100 mm x 80 mm (3.94" x 3.94" x 3.15").

6388 3-Axis DRO Kit, Bench Mill

Hard wired 3-axis DRO package with mounting arm
Designed for LittleMachineShop.com HiTorque bench mills
Complete package, no additional components needed
Advanced display functions
Mounting arm included

Hard wired DRO kit for the HiTorque bench mills. This kit comes with everything you need for a 3-axis bench mill DRO installation. The wiring setup eliminates the need for a wireless environment and ensures regular steady connectivity to your mill. The display has a protective cover which can be used or removed based on your preferences. The read head cable is approximately 58" between read head and an 9-Pin connector. The scales are pre-cut to length for the HiTorque bench mills. See the Compatibility tab for products that work with this product.

6389 3-Axis DRO Kit, Large Bench Mill

Hard wired 3-axis DRO package with mounting arm
Designed for LittleMachineShop.com HiTorque large bench mills
Complete package, no additional components needed
Advanced display functions
Mounting arm included

Hard wired DRO kit for the HiTorque large bench mills. This kit comes with everything you need for a 3-axis lrge bench mill DRO installation. The wiring setup eliminates the need for a wireless environment and ensures regular steady connectivity to your mill. The display has a protective cover which can be used or removed based on your preferences. The read head cable is approximately 58" between read head and an 9-Pin connector. The scales are pre-cut to length for the HiTorque large bench mills. See the Compatibility tab for products that work with this product.

5515 3-Axis Universal DRO Kit for Mini Mills, Bluetooth

Fits milling machines with less than 32" total X-, Y-, and Z-axis travel
Displays on any Android tablet with Bluetooth capability
Resolution of 0.0002" (0.005 mm)
120-240 VAC Power supply
Coolant and dust resistant (IP50)

This magnetic technology digital readout package fits virtually any milling machine with less than 31.8" total X-, Y-, and Z-axis travel. This kit includes 1 meter (39.4") of magnetic scale that you cut to the lengths required for your machine. The instructions tell you how to measure and cut the magnetic scale. This package includes what you need to put a DRO on most any milling (or 3-in-one) machine. It includes a section of scale, three read heads, and a Bluetooth transceiver. Typical mounting bracket designs are included in the instructions. However, due to the wide range of possible applications, appropriate brackets cannot be supplied. You must also get an Android tablet for the display on this DRO. We recommend a 7" screen size, and the tablet must have Bluetooth capability.

5513 Android Tablet, Bluetooth DRO Readout

7" screen size
Bluetooth capable
1024x600 resolution
5V 1000mA power supply
Up to 6 hours of battery life

This Android DRO tablet makes a great readout for our Bluetooth DROs. Bluetooth digital readout software is installed on this tablet, which comes with complete instructions. The software is a customized and fully-licensed version of TouchDRO.

4420 Battery, AG10 Alkaline
These AG10 alkaline batteries fit our DRO display dial units. 11.6 mm diameter, 3.1 mm thick. 1.55 volts (nominal), 65 mAh. These batteries interchange with LR1130 LR55 AG10 L1131 LR110 SR1130 389 189 V10GA

6009 Bolt, DRO Scale Mount, Y-Axis Bench Mill

DRO scale support bolt
Holds Y-Axis DRO scale at appropriate height
Fits HiTorque bench mills with DRO
Fits SIEG SX2.7L bench mills with DRO

Specialized bolt which supports the Y-Axis DRO scale on the HiTorque bench mill with DRO. Also fits SIEG SX2.7L bench mills with DRO. This bolt is fixed to the base of the mill and holds the scale at the appropriate height so that the read head is properly aligned. See Used On tab for reference to machines using this part and the corresponding drawing number.

6146 Bracket Back, Y-Axis DRO Scale, HiTorque Bench Lathe

DRO scale bracket, back
Y-Axis
HiTorque large bench lathe
Fits SIEG SC4 bench lathes with DRO

Back DRO scale bracket for the Y-Axis on the HiTorque large bench lathe and SIEG SC4 bench lathes with DRO. This L shaped bracket holds the DRO scale at the proper distance from the cross slide to ensure alignment with the read head. See Used On tab for reference to machines using this part and the corresponding drawing number.

6148 Bracket Front, Y-Axis DRO Scale, HiTorque Bench Lathe

DRO scale bracket, front
Y-Axis
HiTorque large bench lathe
Fits SIEG SC4 bench lathes with DRO

Front DRO scale bracket for the Y-Axis on the HiTorque large bench lathe and SIEG SC4 bench lathes with DRO. This L shaped bracket holds the DRO scale at the proper distance from the cross slide to ensure alignment with the read head. See Used On tab for reference to machines using this part and the corresponding drawing number.

6008 Bracket, DRO Read Head, Bench Mill

DRO read head mounting bracket
Secures read head to the column mounting block
Fits HiTorque bench mills with DRO
Fits SIEG SX2.7L mills with DRO

Mounting bracket for the DRO read head on the HiTorque bench mills with DRO. Also fits SIEG SX2.7L mills with DRO. This mounting secures the DRO read head to the mounting block which is secured to the mill column. See Used On tab for reference to machines using this part and the corresponding drawing number.

6145 Bracket, DRO Read Head, X-Axis HiTorque Bench Lathe

Bracket, X-Axis read head
Found on HiTorque deluxe bench lathes
Fits SIEG SC4 bench lathes with DRO

Mounting bracket for the X-Axis read head on the HiTorque deluxe large bench lathe and SIEG SC4 bench lathes with DRO. The read head attaches to this bracket and travels along the magnetic scale for accurate position reading. See Used On tab for reference to machines using this part and the corresponding drawing number.

6130 Bracket, Scale, X & Y-Axis, HiTorque Large Bench Mill

DRO read head mounting bracket
For X & Y-Axis DRO scales
Secures read head to the column mounting block
Fits HiTorque large bench mills with DRO
Fits SIEG SX3.5L mills with DRO

X & Y-Axis mounting bracket for the DRO read head on the HiTorque large bench mills with DRO. Also fits SIEG SX3.5L large bench mills with DRO. This mounting secures the DRO read head to the mounting block which is secured to the mill column. See Used On tab for reference to machines using this part and the corresponding drawing number.

6131 Bracket, Scale, Z-Axis, HiTorque Large Bench Mill

DRO read head mounting bracket
For Z-Axis DRO scales
Secures read head to the column mounting block
Fits HiTorque large bench mills with DRO
Fits SIEG SX3.5L mills with DRO

Z-Axis mounting bracket for the DRO read head on the HiTorque large bench mills with DRO. Also fits SIEG SX3.5L large bench mills with DRO. This mounting secures the DRO read head to the mounting block which is secured to the mill column. See Used On tab for reference to machines using this part and the corresponding drawing number.

6469 Bracket, Traditional DRO, Rotating for Lathe

Traditional DRO display mounting arm for lathes
Arm L/W/H is 220mm x 20mm x 40mm (8.7" x 0.79" x 1.6")
Vertical post approx. 80mm (3.1")
Baseplate is 74 mm x 50 mm (2.91" x 1.97")
Comes with mounting hardware

Lathe mounting arm for the hard wired (traditional) DRO display. This mounting arm is designed to be mounted on the backsplash of the lathe, positioned as best meets your needs. The arm can be rotated to the desired angle and tightened into place. The arm is 220mm (8.7") long x 20mm (0.79") wide, and 40mm (1.6") tall. The end of the arm has a 10mm hole which is designed to accommodate the mounting pin on the back of the hard-wired DRO display. The base bracket has two les for mounting hardware. The baseplate is 74 mm x 50 mm (2.91" x 1.97"). The vertical post is approx. 80mm (3.1") from bracket to horizontal arm. The bracket is painted with a high-gloss heavy duty black paint. Bracket comes with mounting hardware.

6468 Bracket, Traditional DRO, Straight for Mills

Traditional DRO display mounting arm for mills
Overall length 360 mm (14.17")
Arm L/W/H is 320mm x 20mm x 40mm (12.6" x 0.79" x 1.6")
Baseplate is 74 mm x 50 mm (2.91" x 1.97")
Comes with mounting hardware

Mill mounting arm for the hard wired (traditional) DRO display. This mounting arm is designed to be mounted on the column of a mill. The arm can be rotated to the desired angle and tightened into place. The arm is 320mm (12.6") from bracket to end, 20mm (0.79") wide, and 40mm (1.6") tall. The end of the arm has a 10mm hole which is designed to accommodate the mounting pin on the back of the hard-wired DRO display. The base bracket has six 6mm holes for mounting hardware. The baseplate is 74mm x 50mm (2.91" x 1.97"). The bracket is painted with a high-gloss heavy duty black paint. Bracket comes with mounting hardware.

5878 Cable, DRO Display Replacement

Connects individual display to sliding DRO scale
6.5ft Overall Length
2 Micro USB (5-pin) Male Ends
Color Black

Replacement cable for 5011, 5012, and 5596 scales

5567 Digital Position Readout, 2-Axis 20 TPI Mini Lathe

This DRO kit is an upgrade for the LMS 4200 7x12 mini lathe
Mounts right on the cross slide and compound rest to give you accurate depth-of-cut readings
Resolution: 0.0001", accuracy: 0.001"
Buttons for on/off, zero, and inch/mm
Includes compound rest bottom and cross slide nut (not shown)

This DRO kit is an upgrade for the LMS 4200 7x12 mini lathe. This kit also fits other 20 TPI mini lathes as sold by Micro Mark.

5497 Digital Position Readout, 2-Axis Bluetooth for HiTorque Bench Lathe

Fits HiTorque Bench lathes
Displays on any Android tablet with Bluetooth capability
Resolution of 0.0002" (0.005 mm)
120 -240 VAC Power supply
Coolant and dust resistant (IP50)

This magnetic technology digital readout package fits LittleMachineShop.com 3536, 3540, and 7500 bench lathes as well as SIEG C4 and SC4 lathes. This package includes what you need to put a DRO on most any bench lathe. It includes a two scales, two read heads, and a Bluetooth transceiver and all the mounting brackets and hardware. You must also get an Android tablet for the display on this DRO. We recommend a 7" screen size, and the tablet must have Bluetooth capability.

5495 Digital Position Readout, 2-Axis Bluetooth for Mini Lathe

Fits standard mini lathes, 7x10 to 7x16
Displays on any Android tablet with Bluetooth capability
Resolution of 0.0002" (0.005 mm)
100-240 VAC power supply
Coolant and dust resistant (IP50)

This magnetic technology digital readout package fits all mini lathes from 7x10 to 7x16. Simply cut the long scale to fit. This package includes what you need to put a DRO on most any mini lathe. It includes a two scales, two read heads, and a Bluetooth transceiver and all the mounting brackets and hardware. You must also get an Android tablet for the display on this DRO. We recommend a 7" screen size, and the tablet must have Bluetooth capability. The specifications shown here show the capabilities of the software included with our Android tablet (PN 5513, available separately) and TouchDRO, and app you can download and install on your own tablet.

5675 Digital Position Readout, 2-Axis Mini Lathe

This DRO kit is specifically made for the 7x10, 7x12, and 7x14 mini lathe
Mounts right on the cross slide and compound rest to give you accurate depth-of-cut readings
Resolution: 0.0001", accuracy: 0.001"
Buttons for on/off, zero, and inch/mm
Fits SIEG C2/SC2 and HiTorque mini lathes

This digital position readout works with most 7x10, 7x12, or 7x14 lathes made by SIEG (C2 and SC2), which includes almost all the mini lathes sold in the US and most of the mini lathes sold world-wide. It also works with HiTorque mini lathes. This kit does not work on 20 TPI mini lathes as sold by Micro Mark. See the Compatibility tab for machines that work with this product.

5514 Digital Position Readout, 3-Axis Bluetooth for HiTorque Mini Mill

Fits large-table solid column mini mills
Displays on any Android tablet with Bluetooth technology
Resolution of 0.0002" (0.005 mm)
120 -240 VAC Power supply
Coolant and dust resistant (IP50)

This magnetic technology digital readout package fits large-table, solid column mini mills including the HiTorque Mini Mill and the SIEG X2D. This package includes what you need to put a DRO on most mini mills. It includes a three scales, three read heads, a Bluetooth transceiver and all the mounting brackets and hardware. You must also get an Android tablet for the display on this DRO. We recommend a 7" screen size, and the tablet must have Bluetooth capability.

5492 Digital Position Readout, 3-Axis Bluetooth for Mini Mill

Fits most tilting column mini mills
Displays on any Android tablet with Bluetooth capability
Resolution of 0.0002" (0.005 mm)
120 -240 VAC Power supply
Coolant and dust resistant (IP50)

This magnetic technology mini mill DRO package fits most tilting column mini mills. This package includes what you need to put a DRO on most mini mills. This 3-axis digital readout for milling machines includes a three scales, three read heads, a Bluetooth transceiver and all the mounting brackets and hardware. You must also get an Android tablet for the display on this DRO. We recommend a 7" screen size, and the tablet must have Bluetooth capability.

5880 Digital Position Readout, Bench Lathe Tailstock

This DRO kit is specifically made for the C4/SC4 bench lathe tailstocks
Mounts right to the back of the tailstock to give you accurate quill depth readings
Resolution: 0.0001", accuracy: 0.001"
Buttons for on/off, zero, and inch/mm
Handwheel: 80 mm OD, 8 mm bore, 2 mm key

This digital position readout for the tailstock works with C4 lathes made by SIEG. Designed for the C4 and SC4 class of bench lathes including HiTorque bench lathes. Kit includes a digital readout, handwheel, bracket, feed screw thrust bearing and fasteners. Handle of handwheel is not provided in kit however the handwheel bolt and handle from your machine should fit. The new handwheel, like the original, has a 6mm thread. For new handle parts, see related products link. See the Compatibility tab for machines that work with this product.

4197 Digital Position Readout, Drill Press, iGaging

Drill press digital readout (DRO)
Easy to read LCD display
Hardened stainless steel beam
Range: 0 - 5"/125 mm, Accuracy: 0.001"
Resolution: 0.0005"/0.01 mm/ 1/64"

The iGaging EZ-Depth Drill Press DRO improves the accuracy and precision of your hole drilling. It is attached directly to the collar on the quill and the side frame of the drill press. Zero the display with the drill in contact with the workpiece, then use the digital display to measure the drilled depth. Display includes fractional inch, decimal inch, and millimeters. Buttons include On/Off/0 button, INC button for toggling between absolute and incremental mode, and a Mode button to change measurement display. Instructions include four mounting methods to suit different drill press designs. IP54 protective rating for moisture and dust resistance. Includes double rail mounting brackets, installation parts and tools as well as a 3V CRF2032 battery.

5879 Digital Position Readout, Mini Lathe Tailstock

This DRO kit is specifically made for the 7x10, 7x12, 7x14 and 7x16 mini lathe tailstocks
Mounts right to the back of the tailstock to give you accurate quill depth readings
Resolution: 0.0001", accuracy: 0.001"
Buttons for on/off, zero, and inch/mm

This digital position readout for the tailstock works with almost all 7x10, 7x12, or 7x14 lathes made by SIEG, which includes most of the mini lathes sold in the US and most of the mini lathes sold world-wide. *NOTE* We've found that the bore in the gray DRO retainer from these kits generally fits most tailstock retainers, but there is some variance in tailstock retainer size. The gray DRO retainer in this kit may require some additional boring (typically less than 1/8") in order to mount it on to your existing tailstock retainer.

6282 Digital Position Readout, X-Axis Compound Slide, Mini Lathe

This DRO kit for the 7x10, 7x12, and 7x14 mini lathe
Compound slide components only
Mounts right on the compound rest to give you accurate depth-of-cut readings
Resolution: 0.0001", accuracy: 0.001"
Buttons for on/off, zero, and inch/mm

This is one half of the DRO kit P/N 5675 for the X-Axis compound slide. Buy this kit if you only need a new compound slide readout and associated parts. This kit replaces the older style gray digital readouts.

6283 Digital Position Readout, Y-Axis Cross Slide, Mini Lathe

This DRO kit for the 7x10, 7x12, and 7x14 mini lathe
Cross slide components only
Mounts right on the cross slide to give you accurate depth-of-cut readings
Resolution: 0.0001", accuracy: 0.001"
Buttons for on/off, zero, and inch/mm

This is one half of the DRO kit P/N 5675 for the X-Axis cross slide. Buy this kit if you only need a new cross slide readout and associated parts. This kit replaces the older style gray digital readouts.

6467 DRO Read Head with 9-Pin Connector

Magnetic read head for SIEG hard wired DRO
Approx.58" (1.5 meters) overall length
Includes scale wiper
Sturdy 9-Pin connector pre-mounted

This is a read head and cable for the DRO kits for bench lathes and bench mills. This product differs from our other DRO kit read head/cables in that it has a 9-Pin connector on one end that connects directly to the SIEG DRO display (P/N 6464). For the same read head with an open wire end, see P/N 5499. The cable is approximately 58" between read head and 9-Pin connector. Includes scale wiper. See the Compatibility tab for products that work with this product.

5012 DRO Scale, 12" (300 mm) with Display

12" travel stainless steel scale
Absolute origin zero memorized when unit is powered on
Large LCD displays in inch/metric/fractions
Articulating arm allows stacking of multiple displays
IP54 Protective rating: Moisture and dust resistance

Twelve inch (300 mm) DRO scale with display and mounting bracket. This iGaging DRO unit is significantly more robust than other inexpensive scales that are available. There are no batteries in the scale units, and the scale units are permanently wired. No square rubber plugs to cause issues. The unit has a moisture and dust resistance rating of IP54. The plug into the display unit is a micro USB plug (though not wired as USB), so it's pretty robust. And each display has a strain relief to prevent stress on the plug. Scale is made of hardened stainless steel for high accuracy and repeatability. Functions include display in inch/metric/fractions, hold button, origin button, absolute/incremental setting and a preset function. Displays are equipped with magnets to allow easy attachment to steel surfaces. The articulating arm allows stacking of multiple displays (see Chris' Tips). Kit includes 2 different types of mounting brackets for flexibility of installation. Each display unit contains two CR2032 lithium batteries for long life. For an AC power supply, see P/N 1177 in related products. Range (travel): 0-12" (300 mm) Accuracy: 0.0015" (0.03 mm) Resolution: 0.0005" (0.01 mm) Total beam length: 16.5" Distance between mounting brackets: 17.25" Remote cable length: 76"

5596 DRO Scale, 24" (600 mm) With Display

24" travel stainless steel scale
Absolute origin zero memorized when unit is powered on
Large LCD displays in inch/metric/fractions
Articulating arm allows stacking of multiple displays
IP54 Protective rating: Moisture and dust resistance

Twenty-four inch (600 mm) DRO scale with display and mounting bracket. This iGaging DRO unit is significantly more robust than other inexpensive scales that are available. There are no batteries in the scale units, and the scale units are permanently wired. No square rubber plugs to cause issues. The unit has a moisture and dust resistance rating of IP54. The plug into the display unit is a micro USB plug (though not wired as USB), so it's pretty robust. And each display has a strain relief to prevent stress on the plug. Scale is made of hardened stainless steel for high accuracy and repeatability. Functions include display in inch/metric/fractions, hold button, origin button, absolute/incremental setting and a preset function. Displays are equipped with magnets to allow easy attachment to steel surfaces. The articulating arm allows stacking of multiple displays (see Chris' Tips). Kit includes 2 different types of mounting brackets for flexibility of installation. Each display unit contains two CR2032 lithium batteries for long life. For an AC power supply, see P/N 1177 in related products. Range (travel): 0-24" (600 mm) Accuracy: 0.002" (0.051 mm) Resolution: 0.0005" (0.01 mm) Total beam length: 28.5" Distance between mounting brackets: 29.25" Remote cable length: 76"

5011 DRO Scale, 6" (150 mm) With Display

6" travel stainless steel scale
Absolute origin zero memorized when unit is powered on
Large LCD displays in inch/metric/fractions
Articulating arm allows stacking of multiple displays
IP54 Protective rating: Moisture and dust resistance

Six inch (150 mm) DRO scale with display and mounting bracket. This iGaging DRO unit is significantly more robust than other inexpensive scales that are available. There are no batteries in the scale units, and the scale units are permanently wired. No square rubber plugs to cause issues. The unit has a moisture and dust resistance rating of IP54. The plug into the display unit is a micro USB plug (though not wired as USB), so it's pretty robust. And each display has a strain relief to prevent stress on the plug. Scale is made of hardened stainless steel for high accuracy and repeatability. Functions include display in inch/metric/fractions, hold button, origin button, absolute/incremental setting and a preset function. Displays are equipped with magnets to allow easy attachment to steel surfaces. The articulating arm allows stacking of multiple displays (see Chris' Tips). Kit includes 2 different types of mounting brackets for flexibility of installation. Each display unit contains two CR2032 lithium batteries for long life. For an AC power supply, see P/N 1177 in related products. Range (travel): 0-6" (0-150 mm) Accuracy: 0.001" (0.02 mm) Resolution: 0.0005" (0.01 mm) Total beam length: 10.5" Distance between mounting brackets: 11.25" Remote cable length: 76"

6464 LittleMachineShop.com DRO Display

DRO Display for hard wired DRO kits
Made for HiTorque bench mills and lathes
Comes with protective cover and can be used with cover on or off
Three 9-Pin connection ports allow use in both 3-axis and 2-axis application

DRO display for the hard wired 2-axis and 3-axis DRO kits for HiTorque bench mills and bench lathes. This display comes with a protective cover which can be kept on the display during use. It is designed to be used with either a vertical or horizontal stand for mill or lathe. The display comes with three 9-Pin ports for constant connection to the machine. See the Compatibility tab for products that work with this product.

6049 Mounting Block, X-Axis DRO Read Head

Mounting block for the X-Axis DRO bracket
Secures read head bracket to mill column
Fits HiTorque bench mills with DRO
Fits SIEG SX2.7L mills with DRO
13x24x10 mm

Mounting block for the X-Axis DRO read head on the HITorque bench mills and SIEG SX2.7L mills with DRO. This block secures the DRO scale mounting bracket to the column of the mill to ensure stability of the read head as it moves along the X-Axis scale. See Used On tab for reference to machines using this part and the corresponding drawing number.

6048 Mounting Block, Y-Axis DRO Read Head

Mounting block for the Y-Axis DRO bracket
Secures read head bracket to mill column
Fits HiTorque bench mills with DRO
Fits SIEG SX2.7L mills with DRO
24x10x8 mm

Mounting block for the Y-Axis DRO read head on the HITorque bench mills and SIEG SX2.7L mills with DRO. This block secures the DRO scale mounting bracket to the column of the mill to ensure stability of the read head as it moves along the Y-Axis scale. See Used On tab for reference to machines using this part and the corresponding drawing number.

6007 Mounting Block, Z-Axis DRO Bracket

Mounting block for the Z-Axis DRO bracket
Secures read head bracket to mill column
Fits HiTorque bench mills with DRO
Fits SIEG SX2.7L mills with DRO
17x24x10 mm

Mounting block for the Z-Axis DRO read head on the HITorque bench mills and SIEG SX2.7L mills with DRO. This block secures the DRO scale mounting bracket to the column of the mill. See Used On tab for reference to machines using this part and the corresponding drawing number.

1177 Power Supply for DRO Scales With Display

Mains power for your DRO unit
120V input
Plugs into display unit

This is an AC adapter power supply for the DRO Scales with Display. It plugs into the side of the display unit.

5499 Read Head, Bluetooth DRO Magnetic

Magnetic read head for Bluetooth DRO
1 meter in length
Includes scale wiper

This is a read head for the Bluetooth DRO system. Get one of these for each axis you need. The cable is one meter long. Includes scale wiper. See Used On tab for reference to machines using this part and the corresponding drawing number.

5673 Readout, DRO

Buttons for on/off and mm/inch
Replacement part for numerous DRO assemblies or machines
Used in 2-axis DRO package for mini lathes
Used in 2-axis DRO package for 20 TPI mini lathes
Used in DRO package for mini lathe tailstock

Digital readout for the Littlemachineshop.com lathes and tailstocks with a non-Bluetooth DRO readout. This readout by itself is not useful without the rest of the DRO package. See related products for full assemblies or kits using this readout. As a replacement part, see compatibility tab for reference to machines or other related products that use this product. See Used On tab for reference to machines using this part and the corresponding drawing number.

1440 Rotary Table DRO Conversion Kit

Conversion Kit for 4" Precision Rotary Table
Save money by upgrading your existing table to DRO

Convert the LittleMachineShop.com 4" Precision Rotary Table (P/N 1810) to a rotary table with digital read out (DRO). This conversion kit will essentially convert our #1810 rotary table to one like part number 2420. For existing owners of the #1810, this unit saves money by upgrading your existing table to DRO.

5498 Scale, DRO Magnetic 1 Meter

Includes 6 end cap mounts
Cut to required lengths
Aluminum frame and stainless cover protects magnetic scale
8.5 x 16 mm (0.33 x 0.63") Cross section
Fit both Bluetooth and hardwired DRO kits

Each one-meter section of magnetic scale includes six plastic end caps for mounting. When measuring a scale for cutting, measure the length of the aluminum channel before the end caps are installed. One meter (39") is enough for a three-axis DRO on most small mills. The scale consists of an extruded aluminum channel with a magnetic strip in the channel. The magnetic strip is protected by a stainless strip. You simply cut the scale to the lengths you need and install the plastic end caps. Measure the travel of your machine and cut the scales to the full travel plus 2.5". This allows for the width of the read head plus about 0.5" for over travel.

6160 Stand, DRO Display, HiTorque Bench Lathe

DRO tablet stand
For Bluetooth DRO display
Can be moved for ideal viewing position
Comes with HiTorque deluxe bench lathe with Bluetooth DRO

DRO tablet display stand used with the HiTorque deluxe bench lathe (SIEG SC4) with Bluetooth DRO. The stand will hold a typical table and may be positioned around the top of the lathe for optimum viewing angle. See Used On tab for reference to machines using this part and the corresponding drawing number.

6147 Stud M3x34.5, DRO Read Head Mounting

Threaded stud
Attaches DRO read head to cross slide
Fits HiTorque deluxe large bench lathe
Fits SIEG SC4 bench lathes with DRO
Size M3x34.5

Connection stud with threading on both ends to secure the DRO read head to the cross slide. As the cross slide is moved along the Y-Axis, the DRO scale moves along the read head. The size is 3x34.5 mm. See Used On tab for reference to machines using this part and the corresponding drawing number.

6452 Stud M4x28, DRO Read Head Mounting

Double Ended Stud, M4x28
Nominal length 28 mm, Diameter 4 mm
Long threaded section 14 mm
Unthreaded section 14 mm
Short threaded section 4 mm

Double ended stud. The stud is M4x28. Here are the specific dimensions. Nominal length 28 mm Long threaded end 14 mm Short threaded end 4 mm Unthreaded portion 14 mm See Chris' tips on measuring double ended studs. See the Compatibility tab for machines and other products that work with this product.

5521 Tablet Stand, Tabletop

Tablet Stand
Stands alone on tabletop
Used for DRO bluetooth Android tablet
Fits most 7" and larger tables

This stand fits our Android tablet used as a display for the Bluetooth DRO. It will fit most 7" and larger tablets.

5501 Transceiver, Bluetooth DRO

Works with Android tablets and phones
3-Axis capability

This 3-axis Bluetooth transceiver works with any Android tablet or phone with Bluetooth capability. It mounts to the machine magnetically. A 100-240V AC power supply is included.

6453 Y- Axis DRO Magnetic Scale Bracket

Magnetic scale mounting bracket - Y-axis
Used on X2 mini mills
220mm x 16mm x 8&5mm, holes 210mm on center

Mounting bracket for the Y-axis DRO magnetic scale on X2 and other mini mills. Mounts on side of table and step-up on bracket matches table side. See Used On tab for reference to machines using this part and the corresponding drawing number.
